Amplifier Power-up Process:
The CONNECTSERIES is ready to pass audio straight out of the box. Here’s what you’ll get with your new amplifiers and a quick demonstration on how to power it up.
Unboxing
Unboxing your CONNECTSERIES unit for the first time? Here’s what you’ll find in your box:
- IEC Power Cord
- Quick Start Guide
- Record of Excellence
- Welcome Card
- Shark Fin Logo Sticker
- 3-position 5.08mm Amphenol Anytek Input Connectors (For inputs and External I/O port) – Part #: CSP10006-1 & CSP10001-1
- 2-position 7.62mm Amphenol Anytek Output Connectors – Part #: CPP10001-1 (350/700W only) & CPP10006-1 (80/160W only)
- Rack Screws – Part #: MSI10007-1
- Rear Rack Supports – Part #: MFM10003-1
Power-up Process
Follow along with the below procedure to properly power-up your CONNECTSERIES amplifier.
- You will notice there are no buttons on the front panel. This is intentional and prevents unwanted adjustments.
- Plug the unit in. You will notice the shark fin on the front panel turn GREEN as well as the small LED below the power button on the back panel.
- To power on the unit, on the back, you will notice a power icon above the power button. Press that button and an LED below will illuminate BLUE. The amplifier has now turned on and begun it’s boot sequence.
- Boot up takes roughly 15 seconds. Once completed, the front panel shark fin will be BLUE, the display screen will show the amplifier information, and the channel “Ready” LEDs will be illuminated GREEN.
If you have any questions or feedback about unboxing your unit or the power-up process, please leave a comment below or reach out to us on our social media channels.
